DISCOVER THE DESTRESS SOLUTION - eVu TPS + BioGraph

ProComp Infiniti - 8 Channel Biofeedback & Neurofeedback System v6.0

Rating:
100% of 100
  • Industry leading data acquisition and biofeedback
  • Complete range of physiological sensors available
  • Powerful, versatile BioGraph Infiniti software
  • Includes your choice of 360 Suite or Rehab Suite
Our Part #
TTL T7520M
Manufacturer Part #
T7500M

In Stock
$3,995.00
Brand
Shop With Us
  • Extremely knowledgeable staff
  • Save with our free Loyalty Program
  • Most items ship in 1 business day
  • Not in the USA? We ship international
Need Financing?
Get 6 months to pay on $99 or more

The ProComp Infiniti is an 8 channel biofeedback and neurofeedback system with the power needed for real-time data acquisition in any clinical or educational setting.

The ProComp Infiniti has eight protected pin sensor inputs with two channels sampled at 2048 sampes per second and six channels sampled at 256 samples per second.

The first two sensor channels of the ProComp Infiniti encoder provide ultimate signal fidelity for viewing raw EEG, EMG and EKG signals (2048 samples per second). The remaining six channels can be used with any combination of sensors, including EEG, EKG, RMS EMG, skin conductance, heart rate, blood volume pulse, respiration, goniometry, force, and voltage input.(256 samples/sec) Sensors are not included with this system.

ProComp Infiniti offers internal, user-activated calibration to ensure that you can always obtain the highest quality signal, without the costly downtime associated with factory re-calibration.

In short, the ProComp Infiniti covers the full range of objective physiological signals used in clinical observation and biofeedback.

Housed in an ergonomically designed case and requiring only a USB port, ProComp Infiniti can be used with any PC laptop or desktop. ProComp Infiniti can capture data in real time by connecting directly to the PC via fiber-optic cable, or it can store data on a Compact Flash memory card for uploading later to the PC.

HARDWARE FEATURES
  • USB connection
  • Internal user activated re-calibration
  • Ability to save directly to Compact Flash Memory Card
  • Integrated impedence checking
  • Higher Sampling rate
  • Automatic sensor recognition
  • Internal user activated re-calibration
  • Ergonomic design
  • Easy accessible dip switches
  • Recessed fiber optic plug
  • One Year Warranty
SOFTWARE FEATURES
  • Realtime frequency analysis
  • User programmable waveform arithmetic, statistics/DSP
  • Fast 3D spectral arrays
  • Software filters to export data to Microsoft Excel for further calculations
  • Realtime events and markers
Write Your Own Review
You're reviewing:ProComp Infiniti - 8 Channel Biofeedback & Neurofeedback System v6.0
Your Rating
You have submitted no questions.
Ask Your Question
Jot us a note and we’ll get back to you as quickly as possible.

Infiniti Software

The BioGraph Infiniti software is created in a modular fashion to ensure you get only what you need and do not fill your computers memory with unwanted software. The Developer Tools will allow for high end users to create their own screens, scripts and channel sets. This ultimately provides the customer with the most variety under one system.

The ProComp Infiniti hardware comes with the BioGraph Infiniti software and the BioGraph Infiniti 360 Suite.

ProComp Encoder Comparison

FlexComp Infiniti ProComp Infiniti ProComp5 ProComp2
Channels 10 8 5 2
Compatible Sensors EEG, SCP/EP, EMG, EKG, BVP(Blood Volume Pulse), Respiration, Temperature, Skin Conductance, Inclinometer, Algometer / Force, Bend, Foot Switch, Hand Push Button, Voltage Isolator, Force Adapter, Goniometer / Torsiometer Adapter, HEG The same as FlexComp Infiniti The same as FlexComp Infiniti The same as FlexComp Infiniti
Sensor Type External sensors External sensors External sensors 1 Internal EEG on Channel A. External sensors on B, C & D
Impedance check
(with EEG-Z sensor)
All channels All channels All channels Channel B only
Sampling Rate 2048 samples/sec on all 10 channels 2048 samples/sec
on Channel A and B,
256 samples/sec
on Channel C, D, E, F, G, H
2048 samples/sec
on Channel A and B,
256 samples/sec
on Channel C, D, E
256 samples/sec
on Channel A and B,
32 samples/sec
on Channel C and D
Connection to PC Fiber Optic to USB through TT-USB interface unit. Or Compact Flash Module Bluetooth Tele-Infiniti The same as FlexComp Infiniti The same as FlexComp Infiniti Fiber Optic to USB (TT-USB) or COM port (Pro-SB) or Tele-Infiniti
Software and Suites BioGraph Infiniti, Developer Tools, EEG Suite, Physiology Suite, and DynaMap Suite BioGraph Infiniti, Developer Tools, either EEG Suite or Physiology Suite The same as ProComp Infiniti The same as ProComp Infiniti
Weight 200g (7oz) 200g (7oz) 200g (7oz) 40 g (1.4oz)
Size 5.1" x 3.7" x 1.5"
(130 mm x 95 mm x 37 mm)
The same as FlexComp Infiniti The same as FlexComp Infiniti 2.2" x 2.8" x 0.75"
(55 mm x 71 mm x19 mm)
Self-calibration Yes Yes Yes No
Compact Flash
Memory Storage
Yes Yes Yes No
Power Source 4AA batteries, single-use alkaline or NiMH rechargeable The same as FlexComp Infiniti The same as FlexComp Infiniti 1 AA battery, single-use alkaline or NiMH rechargeable
Battery Life (alkaline) 30 hours typical, 20 hours minimum The same as FlexComp Infiniti The same as FlexComp Infiniti 10 hours typical
  • 8-channel ProComp Infiniti encoder unit
  • BioGraph Infiniti Software
  • BioGraph Infiniti 360 Suite
  • Developer Tools
  • TT-USB interface unit
  • Fiber-optic cables (12 inch & 15 foot)
  • Four alkaline AA batteries
  • Sleek fabric storage and carrying case

ProComp Infiniti Hardware Quick Start & User's Guide

360 Suite User Manual

Procomp Infiniti Hardware Manual

Computer Requirements

View Computer Requirements for Thought Technology software (opens in a new browser tab)

Specifications

  • 15 Foot Fiber Optic Cable to USB (TT-USB interface) or COM port(Pro-SB)
  • Impedance check (with optional EEG-Z sensor)
  • Self-calibration: Yes
  • Fast Channels: 2 channels, 2048 samples/sec DC-45Hz
  • Slow channels: 5 channels 256 samples/sec DC-8Hz (shared with fast channels)
  • Power Source: 4 1.5V AA Battery (20+ hours)
  • Size (approx.) 130mm x 95mm x 37mm (5.1 x 3.7 x 1.5)
  • Weight (approx.) 200g (7oz)
  • Power Source 4AA batteries, single use alkaline or NiMh Rechargeable
  • Supply Voltage 3.6V 6.5V (fiber optic), minimum 4.0V (Compact Flash)
  • Battery Life, Alkaline cells 30h typical, 20h minimum
  • Low-battery warning 20 30 minutes of battery life remaining
  • Sensor supply voltage 7.260V 2mV
  • ADC output 14bits
  • Full-scale input range, DC 2.8V1.696V
  • LSB magnitude 207uV
  • Encoder channel bandwidth (3dB) and sample rate
    • DC 512Hz @ 2048 samples/second
    • DC 64Hz @ 256 samples/second
    • DC 64Hz @ 200 samples/second
    • DC 8Hz @ 32 samples/second
    • DC 8Hz @ 20 samples/second
  • Anti-aliasing Filter 5th order Butterworth
  • Alias rejection 30dB typical
  • DC gain accuracy 0.5% (initial, or after self-calibration)
  • DC offset 3LSB (initial, or after self-calibration)
  • Overall system accuracy 5%
  • Offset drift, calibration temperature 10C 5 LSB
  • Encoder noise 150uV RMS, 1mV p-p typical, offset removed

General Requirements for Safety Compliant: UL60601-1 (R2003), CSA C22.2 601.1-M90 (R2005)

NOTE: ProComp Infiniti and its Sensor Heads and sensors are sensitive electronic instruments and should be handled as such. Be especially careful to avoid both pulling on the sensor cables and leads or getting moisture and gel on the sensor snaps. If necessary, wipe the surface with a damp cloth or use a moistened Q-tip to remove gel from inside the sensor snaps. Wipe with a dry cloth.
